800_5Series
800-5 Series
DOWNLOAD BROUCHERFeatures :
Highly recommended for use on thin walled tubes (19 thru 22 gage walls) of Stainless Steel, Titanium, Incoloy and other exotic material. Advantage : Gives a more concentric and even expansion when expanding thin walled tubes vs. a conventional 3 roll expander and reduce tube spring back effect
| For Tube Sheet Adjustable Range | ||
|---|---|---|
| Tube Expander Fitted With Roller Length | Minimum A | Miximum B |
| (38.1mm) 1.1/2" | (12.7mm) 1/2" | (38.1mm) 1.1/2" |
| (57.1mm) 2.1/4" | ((31.7mm) 1.1/4" | (57.1mm) 2.1/4" |
